DT830D Digital Multimeter
Basic 3½-digit digital multimeter for students and hobbyists. Measures DC/AC voltage, DC current, resistance, diodes and transistor gain – the first tool for any electronics bench.
- Display
- 3½ digit LCD, 1999 counts
- DC Voltage
- 200 mV / 2 / 20 / 200 / 1000 V
- AC Voltage
- 200 / 750 V
- DC Current
- 200 µA / 2 / 20 / 200 mA / 10 A
- Resistance
- 200 Ω – 2 MΩ
- Other Functions
- Diode test, transistor hFE
₹0.00
( Include all taxes )1
7 Days Return
Cash On Delivery
Safe & Secure
Specifications
- Manufacturer Part Number
- DT830D
- Display
- 3½ digit LCD, 1999 counts
- DC Voltage
- 200 mV / 2 / 20 / 200 / 1000 V
- AC Voltage
- 200 / 750 V
- DC Current
- 200 µA / 2 / 20 / 200 mA / 10 A
- Resistance
- 200 Ω – 2 MΩ
- Other Functions
- Diode test, transistor hFE
- Ranging
- Manual
- Power
- 9 V battery
- Size
- About 126 × 70 × 26 mm
Description
A simple, light meter that covers the measurements you need when learning electronics: check battery and supply voltages, test resistors, find the polarity of a diode or LED, and measure small currents.
Features
- 3½-digit LCD (1999 counts)
- DC voltage 200 mV – 1000 V, AC voltage 200 V – 750 V
- DC current 200 µA – 10 A (10 A on a separate jack)
- Resistance 200 Ω – 2 MΩ
- Diode test and transistor hFE socket
- Manual range selection, 9 V battery
Safety
This is a basic meter meant for low-voltage electronics. Always set the dial before connecting, move the red lead back to the V/Ω jack after measuring current, and don't use it on mains distribution boards or high-energy circuits.
Package includes
1 × DT830D multimeter, 1 × pair of test leads, 1 × 9 V battery (fitted)
