3mm Red LED (Through-Hole DIP) – Pack of 10

Bright 3mm red through-hole LED for indicator lights, status LEDs and breadboard projects. Works with Arduino, ESP32 and Raspberry Pi using a series resistor. Pack of 10.

Type
Through-hole (DIP) LED
Colour
Red
Diameter
3 mm
Lens
Water clear
Wavelength
620–635 nm
Forward Voltage
1.8–2.2 V
₹0.00
( Include all taxes )
1
7 Days Return
Cash On Delivery
Safe & Secure

Specifications

Manufacturer Part Number
C503B-RAN
Type
Through-hole (DIP) LED
Colour
Red
Diameter
3 mm
Lens
Water clear
Wavelength
620–635 nm
Forward Voltage
1.8–2.2 V
Forward Current
20 mA (max)
Viewing Angle
30–40°
Pack Quantity
10 pieces

Electrical characteristics

Absolute maximum ratings

Going above these limits can permanently damage the part. Design with a safety margin and use the typical values below for normal operation.

  • Forward currentIF
    Max rating
    50 mA
  • Peak forward currentIFP
    Max rating
    200 mA
  • Reverse voltageVR
    Max rating
    5 V
  • Power dissipationPD
    Max rating
    130 mW

Typical characteristics

  • Forward voltageVF
    Condition: IF = 20 mA
    Min
    —
    Typ
    2.1 V
    Max
    2.6 V
  • Reverse currentIR
    Condition: VR = 5 V
    Min
    —
    Typ
    —
    Max
    100 µA

Downloads

Description

A standard 3 mm red LED with two long legs – solder it into a PCB or plug it straight into a breadboard. Ideal as a power or status indicator, in beginner and school projects, or anywhere you need a small, bright red light.

Features

  • 3 mm round body with through-hole (DIP) leads
  • Bright red light, low power (10–20 mA)
  • Long leg = anode (+), short leg / flat edge = cathode (–)
  • Works on 3.3 V and 5 V boards with a series resistor

How to use

Always connect a resistor in series: 150–220 Ω on 5 V, or 68–100 Ω on 3.3 V. Without a resistor the LED will burn out.

Package includes

10 × 3 mm red LED
