Temperature & Humidity SensorsCompatible
DHT22 (AM2302) Temp & Humidity Sensor
More accurate big brother of the DHT11: −40 to 80 °C and 0–100 % RH on one data wire. Module with pull-up resistor fitted – ready for Arduino, ESP32 and Raspberry Pi.
- Sensor
- DHT22 / AM2302
- Humidity Range
- 0–100 % RH
- Humidity Accuracy
- ±2 % RH (typ.)
- Temperature Range
- −40 to 80 °C
- Temperature Accuracy
- ±0.5 °C
- Resolution
- 0.1 % RH / 0.1 °C
₹0.00
( Include all taxes )1
7 Days Return
Cash On Delivery
Safe & Secure
Specifications
- Manufacturer Part Number
- AM2302
- Sensor
- DHT22 / AM2302
- Humidity Range
- 0–100 % RH
- Humidity Accuracy
- ±2 % RH (typ.)
- Temperature Range
- −40 to 80 °C
- Temperature Accuracy
- ±0.5 °C
- Resolution
- 0.1 % RH / 0.1 °C
- Output
- Single-wire digital
- Supply Voltage
- 3.3–6 V
- Sampling Interval
- 2 s minimum
- Pins
- VCC, DATA, GND
Description
When the DHT11 isn't precise enough, the DHT22 (also sold as AM2302) is the drop-in upgrade. Same wiring, same libraries, but a much wider range and better accuracy – good for greenhouses, incubators, data loggers and outdoor weather stations.
Features
- Humidity 0–100 % RH, ±2 % RH (typical)
- Temperature −40 to 80 °C, ±0.5 °C
- 0.1 resolution for both readings
- 3.3–6 V supply, single-wire digital output
- Module version with pull-up resistor: VCC, DATA, GND
Good to know
Read it no faster than once every 2 seconds. In the Arduino DHT library, select type DHT22.
Package includes
1 × DHT22 (AM2302) module
